This item has been discontinued. Leaving this page up for reference.
Price: Discontinued.
European Beech $489
Natural Oiled Walnut $499
Domestic shipping: $free
International Priority Shipping: $39
Requires an 18volt power supply with a negative tip that can deliver at least 150ma. (Not included.) Buy one here.
**International shipping charges are estimated. We will invoice you for the shipping once we can determine the exact cost to your country. Feel free to message us with any questions.
Please read:
Due to increased costs of the meter and other raw good we are discontinuing this product. The smaller euro-pedal version will continue to be available. I really love this pedal design. Fact of the matter is that when we order the meters there are always ones that don’t meet retail standards. Sometimes its minor scrapes or marks. Other times its smudges that won’t wipe of the plastic glass. Since we buy these from overseas in smaller quantities than major brands, it makes it incredibly hard and costly to return them. The current tariff situation has also not resolved its self.
That may be by design. Offer a full refund but you have to return the items. Shipping is $$$.
…But what ever reason it adds up. I find myself working for less than minimum wage 😂 …QC has been an ever increasing issue since covid. It’s like everything got sloppier and less care goes in to manufacturing. It would be a lot different if there wasn’t waste within every order and I could count on knowing what I’m paying for will arrive 100% perfect.
Legacy post begins here…
It’s finally here, the official Hyde Distortion Filter with an illuminated VU meter. I’ve had a lot of requests to mod and illuminate vintage meters and its not often possible. So after careful consideration we made this alternative. I feel this maintains the image and quality I’m striving for. It comes in ether European Beech in a dark finish or natural oiled walnut.
The circuit is the same Hyde Distortion Filter found on the now discontinued Jekyll n Hyde dual filter boxes and the smaller euro pedal. This version is a step up for folks who would like easier interfacing with standard instruments such as keyboards, drum machines and other guitar pedals while still maintaining eurorack style CV control. It has 1/4″ jacks for the in/out audio signal on the back and an additional LFO out on the top panel. The LFO out can also be used as a CV input for the LPF (low pass filter) the filter will respond differently than with the dedicated LPF CV jack on the front panel.
But what is a Hyde Distortion Filter?
This is a low pass (all analog) diode ladder filter with two distinct pre-distortion circuits. Depending on how the knob is set there is a third district sound where the two signals meet.
This is a lower gain distortion so it works well with noisier synths. Since the filter is being overdriven by the pre-distortions you get a very unusual tonal quality. Tone can be affected by increasing or decreasing the output of whatever instrument or pedal you’re feeding into it.
You can bypass the distortions for a clean input. It has a very slow drifting LFO to keep the filter from sitting in a static position. There is a particular “worble” to this circuit. Much like vintage gear there is a touch of instability. You would hear this predominately when cranking up the resonance and clamping down the filter. Something not easily achieved with plugins or soft synths.
Knob controls:
Up: Pre-Distortion
Hyde: Filter
Fortis: Resonance
Down: Post-Drive
Nefras: LFO Modulation
“Y” LED: LFO Pulse
Blas: LFO Amount
Zeal: LFO Speed
React: Germanium Clipping
**Requires a regulate 18volt DC Supply. Standard negative tip with a min of 150ma. (not included) I recommend this one: the ECB004 You can buy it directly from Sweetwater.
The Hyde Distortion Filter can run on lower voltages for a dirtier sound. For instance a 12volt supply that can provide enough current will drastically change the sound. The lower voltage will affect the smoothness of the filter. Experimenting with lower voltages will not damage anything. Just don’t use more than 18volts.
***All purchases done through Paypal. Units are always shipped ASAP.
****International shipping can vary. Typically I will send a payment request when your unit is ready and I am able to verify exact shipping to your specific location.
